HTT
DESCRIPTION
Mag drive regenerative turbine pumps series HTT are made of thermoplastic materials (polypropylene-PP and PVDF) and are suitable to pump high corrosive liquids. Thanks to the innovative mag drive system, pumps model HTT reduce risks of leakage and emissions and the maintenance costs. The transmission of the motion occurs through magnetic joints without any mechanical seal. This design guarantees the maximum safety and efficiency. The pumped liquid has to be clean and without solids in suspension.
DESIGN OF MAGNETIC DRIVE PUMPS MOD. HTT
Magnetic drive pumps have a particular sealless design that is suitable to pump corrosive and dangerous liquids thanks to the high chemical resistance and absence of leakage and emissions. The structure is really simple so that the pump requires a very reduced maintenance with consequent save in terms of repairing and spare parts costs during the pump life. The external magnet placed on the drive shaft transmits the motion to the internal magnet connected to the impeller which rotates and moves the fluid through the pump.
Applicazioni tipiche:
High corrosive liquids
Toxic, noxious and carcinogenic liquids
Handles up to 20% entrained gas, resists cavitation
MAIN FEATURES
- Plastic injection moulded;
- Materials in contact with the liquid:
- pump head: PP/PVDF;
- Impeller: PVDF;
- O-ring: EPDM/Viton;
- Shaft: pure ceramic Al2O3 99,7%;
- Bushing: PTFEC
- Max capacity: 9 m3/h; Max head: 50 mlc
- Temperature: PP: max 70°C – PVDF: max 90°C
- Max viscosity: 200 cSt
- Pressure rating: NP 6 @ 20°C
